- 2 pole 3 slot hi-torque motor design.
- High purity copper windings maximizes the efficiency.
- Universal fit, fits for all 1/24 and 1/28 brushless car-multi-mounting system for M2.0 screws.
- CNC machined 6061 billet aluminum heatsink can.
- High RPM ABECS oversized bearings.
Features:
1. 2 pole 3 slot hi-torque motor design.
2. CNC machined 6061 billet aluminum heatsink can.
3. High purity copper windings maximizes the efficiency.
4. High RPM ABECS oversized bearings.
5. Universal fit, fits for all 1/24 and 1/28 brushless car-multi-mounting system for M2.0 screws.
6. balanced rotor, smoothness for best reliability and maximun RPM.
7. Stator-supper thin (0.2mm) kaminations.
8. engineered for maximum energy conversion.
Specification:
Condition: Brand New
Material: Metal, Magnet
Color: As Pictures Shown
KV: 9500KV
Watts: 80
Max Voltage: ＜6.0W
Max. Amps: 12A
Rotor Poles: 2
IO: 0.8A
Resistance: 0.1
Max. RPM: 60000
Overall Length: Approx. 3.7cm/1.5in
Diameter: Approx. 1.5cm/0.6in
Motor Length: Approx. 2.5cm/1in
Shaft Diameter: Approx. 0.2cm/0.08in
Weight: Approx. 22g
Package List:
1 * Motor
- Date First Available : December 10, 2019
- Manufacturer : Woyisisi
- Country of Origin : China
